The 3 Most Important Steps in Expediting the Design of Your Membrane Switch keypad

1,Provide Clear, Accurate Design Membrane switch Information
Have you included all the pertinent information?
1,overall size 2,keypad centers 3,LED location 4,diameter of corners 5,size & location of cutouts 6,size & location of windows 7,location of tail exit point 8,location of graphic entities 9,schematic: What side is pin 1 on? 10,color specifications 11,tail length (including connector?) 12,black & white outputs or files of logos & symbols.
2,Answer Design Questions Expeditiously
Soon after your purchase order has been placed, JCF Technology design team will review your design information and com-pile any questions that they may have. An JCF representative will be contacting you to expeditiously address these
issues. Your active participation in resolving these questions is critical for the timely design of your product!
3,Approve Graphic overlay Artwork and membrane keypads Circuitry Schematic in a Timely Fashion
Typically, within 3 days after placing a purchase order, you will receive a email of our blueprint and artwork for ap-proval. Please look over this information carefully. Contact us immediately after its review. In the case of a membrane switch keyboard, we will continue with the design by laying out the circuitry traces. Again, this will be email to you for approval and your timely feedback is essential.
