The 3 Most Important Steps in Expediting the Design of Your Membrane Switch

1,Provide Clear, Accurate membrane switch Design Information

Have you included all the membrane keypads pertinent information?

Are you Providing the Information in the Most Efficient Format?

(In order of preference)

a. AutoCAD Files (.DWG)

b. DXF Files

c. Corel Draw Files (.CDR)

d. Detailed Blueprint (hardcopy)

►overall size

►keypad centers

►LED location

►diameter of corners

►size & location of cutouts

►size & location of windows

►location of tail exit point

►location of graphic entities

►schematic: What side is pin 1 on?

►color specifications

►tail length (including connector?)

►black & white outputs or files of logos & symbols

2,Answer Design Questions Expeditiously

Soon after your purchase order has been placed, JCF design team will review your design information and com pile any questions that they may have. An JCF representative will be contacting you to expeditiously address these ssues. Your active participation in resolving these questions is critical for the timely design of your product!

3,Approve Graphic Artwork and Circuitry Schematic in a Timely Fashion

Typically, within 1 weeks after placing a purchase order, you will receive a email of our blueprint and artwork for approval. Please look over this information carefully. Contact us immediately after its review. In the case of a membrane switch keypad, we will continue with the design by laying out the circuitry traces. Again, this will be email to you for approval and your timely feedback is essential.
