6 types of membrane switch product specifications analysis instructions

Analysis of product specifications for flat touch membrane switches:
The total thickness of the membrane switch is about 0.7mm, and the service life is more than 1 million times. It has good sealing, waterproof, dustproof, and anti-corrosion of harmful materials. Designed according to the overall requirements, colors and patterns can be customized, the size and shape of the buttons can be selected arbitrarily, and characters, trademarks, and display windows can be arbitrarily matched. There are also features of low cost and long life.
Key embossed neutral touch membrane switch analysis product specifications:
The total thickness of the membrane switch is about 0.7mm, and the service life is about 800,000 times. It has the characteristics of beautiful appearance, good sealing, convenient assembly, good touch, low cost and long life. It is widely used in intelligent electronic measuring instruments, electronic weighing instruments, household appliances, electronic communication and industrial automation systems.
Analysis product specifications of the built-in metal dome tactile membrane switch:
The total thickness of the membrane switch is above 0.8mm, and the service life is about 500,000 times. It has the characteristics of beautiful appearance, stable performance, reliable operation, good contacts, and uniform force. According to the design and customer requirements, the metal dome specifications with different operating forces can be selected, including round, triangular, square and other shapes and key strengths.
Built-in LED indicator light / SMD resistance membrane switch analysis product specifications:
The total thickness of the membrane switch is about 0.9mm, and the service life is more than 800,000 times. The LED lights can be installed in different colors according to requirements, generally red, yellow, green, blue, white and high-brightness LED types.
Analysis product specifications of membrane switch with shielding layer circuit:
The total thickness of the membrane switch is about 0.95mm, the service life is more than 800,000 times, the appearance is elegant, the sealing is good, the assembly is convenient, and the anti-electromagnetic interference ability is strong. It is mostly used in equipment and instruments that are sensitive to external electromagnetic interference.
Built-in metal dome FPC flexible circuit membrane switch analysis product specifications:
The total thickness of the membrane switch is more than 0.8mm, and the service life is about 500,000 times. It has the characteristics of beautiful appearance, stable performance, reliable operation, clear contacts, uniform force, low loop resistance, and reliable interface. Usually used in medical equipment, instruments and meters that require high resistance and reliability.
